Automatic permanent magnet jack

5000kgs Permanent magnetic Lifter

Built using Neodymium magnets
No electricity required for use
Small, compact design makes for easy deployment
May be used for a wide range of different metals, bearing in mind the reduction factors for Working Load Limits
Easy to switch on and off by simply turning lever 180º, thus fully leveraging the magnetic effect
Safety mechanism locks lever in position when the magnet is on, thus preventing the accidental release of the load

Specifiaction:

Type	Rated Lifting Capacity (kg)	Dimension LWH (cm)	Max Breakaway Force (kg)	Net Weight	Gross Weight
Type	Rated Lifting Capacity (kg)	Dimension LWH (cm)	Max Breakaway Force (kg)	(kg)	(kg)
JG- 100	100	251616	300	3	4
JG-400	400	322017	1200	10	11
JG-600	600	372321	1800	20	22
JG-1000	1000	432824	3000	37	40
JG-2000	2000	523031	5000	68	74
JG-3000	3000	603031	7500	87	93
JG-4000	4000	683041	10000	113	121
JG-5000	5000	734048	12500	198	213

direct deal automatic permanent magnet lifter 5000kg magnetic lifter steel plate crane lifting electromagnetet

The permanent magnetic lifters are mainly used for lifting the steel plate and round steel, because of the

light weight, ease of operation and powerful suction, magnetic lifters are widely applied in ship engineering,

warehouse, transportation and machinery manufacturing.

5000kgs Permanent magnetic Lifter

    Built using Neodymium magnets
    No electricity required for use
    Small, compact design makes for easy deployment
    May be used for a wide range of different metals, bearing in mind the reduction factors for Working Load Limits
    Easy to switch on and off by simply turning lever 180º, thus fully leveraging the magnetic effect
    Safety mechanism locks lever in position when the magnet is on, thus preventing the accidental release of the load
